Nashville Tune-o-Matic Bridge - Bell Brass (USA Made)
Made in the USA with precision machined bell brass for the bridge, posts and body inserts. The saddles are made from milled steel. Comes complete with a 2mm allen wrench which is used to adjust the intonation.
This bell brass bridge coupled with milled steel saddles offers several sonic benefits - it will tighten up the low end frequencies and also add a little chime to the instrument. On top of this, it will create more string definition and sustain in comparison to standard zinc Tune-o-Matic bridges.
Important Specs and Dimensions:
Bridge material = Milled Bell Brass
Saddle Material = Milled Steel
Thread = M5 - 0.8 Metric (as used by Gibson on Nashville Models)
Post to Post Spacing = 2.93 in. (74.5mm)
Saddle Notch = Centre Notched Saddles
Post/Thumbwheel Material = Brass
Radius = 12 inch
Post Top Width = .15 Inches / 4mm
Bridge Stud Diameter = 4 mm Smooth Top
Bridge Centre To Centre Spacing = 2.93 inches
Saddle Spacing = 10.4 mm
Original: $195.36
-65%$195.36
$68.38
Description
Made in the USA with precision machined bell brass for the bridge, posts and body inserts. The saddles are made from milled steel. Comes complete with a 2mm allen wrench which is used to adjust the intonation.
This bell brass bridge coupled with milled steel saddles offers several sonic benefits - it will tighten up the low end frequencies and also add a little chime to the instrument. On top of this, it will create more string definition and sustain in comparison to standard zinc Tune-o-Matic bridges.
Important Specs and Dimensions:
Bridge material = Milled Bell Brass
Saddle Material = Milled Steel
Thread = M5 - 0.8 Metric (as used by Gibson on Nashville Models)
Post to Post Spacing = 2.93 in. (74.5mm)
Saddle Notch = Centre Notched Saddles
Post/Thumbwheel Material = Brass
Radius = 12 inch
Post Top Width = .15 Inches / 4mm
Bridge Stud Diameter = 4 mm Smooth Top
Bridge Centre To Centre Spacing = 2.93 inches
Saddle Spacing = 10.4 mm
